Gold Note PH-10 Expand

Gold Note PH-10

Gold Note Gold Note

Ny

Phonosteg från italienska Gold Note. Väldig fin balans, bra attack och otroligt fin svärta för prisklassen.

Separata nätdelen PSU-10 rekommenderas starkt.

Väldigt många inställningsmöjligheter gör det enkelt att anpassa till alla pickuper och förstärkare.

XLR och RCA-utgångar

Mer detaljer

19 990 kr

inkl.

The extraordinary phono stage

PH-10 is an ultra-versatile phono preamplifier with unique features, including EQ curve, load and gain adjustment: a fully analogue design crafted with the best components to recreate the musical event in the most natural way possible. To control PH-10 Gold Note has developed the intuitive Single Knob Control (SKC) which, in combination with the color display, allows to quickly adjust any function without interrupting the audio playback. The PH-10 allows selecting the most appropriate equalization curve for each record: RIAA, DECCA LONDON or AMERICAN COLUMBIA, through the menu present on the display. Thanks to our proprietary technology, inspired by the Neumann Cutting Lathe, each curve can be further enhanced with the “enhanced” function.

Nine different loading options [10Ω, 22Ω, 47Ω, 100Ω, 220Ω, 470Ω, 1000Ω, 22KΩ, 47KΩ] and four different gain options selectable [0dB, ± 3dB, +6dB] allow you to accurately adjust the preamplifier and get the best sound experience with any type of MM and MC cartridge. Through the two separate RCA inputs, it is possible to connect two different arms to PH-10, each with independently adjustable settings that can be saved in memory even when the unit is off, ensuring extreme flexibility and intuitiveness. To maximize the performance of PH-10 Gold Note has developed PSU-10, an external super inductive power supply that allows the phono stage to fully express its potential, restoring with extreme realism, three-dimensionality and precision the sound of vinyl.

EQUALISATION CURVE CONTROL - 3 EQ curves (RIAA, Decca London, American Columbia) all with Enhanced option
INFRASONIC FILTER - 10Hz /36dB octave
FREQUENCY RESPONSE - 20Hz /20kHz [Enhanced 20Hz-50kHz] @ +/-0.3dB
THD (Total Harmonic Distortion) <0.05% @1kHz
SIGNAL TO NOISE RATIO - 89dB
DYNAMIC RESPONSE - 105dB
ANALOGUE INPUTS - MM/MC two independent stereo RCA
INPUT SENSITIVITY - 0.1mV MC up to 10.0mV MM
INPUT IMPEDANCE - 9 options [10Ω, 22Ω, 47Ω, 100Ω, 220Ω, 470Ω, 1000Ω, 22kΩ, 47kΩ]
GAIN - 45dB MM to 65dB MC with 4 options [0dB, ± 3dB, + 6dB]
CAPACITANCE (MM ONLY) - 220pF
AUDIO OUTPUTS - 1x unbalanced RCA1x balanced XLR (+12dB)
OUTPUT IMPEDANCE - 50Ω

The story of Gold Note is one of dedication and talent. And, like all business success stories, it is a plural experience: the paths of a vast community of people intertwine in the magnificent headquarters nestled in the Florentine hills. Every day, these people put their skills and abilities at the service of the same goal, the Italian sound.


But in the beginning was Maurizio Aterini. It’s the end of the Seventies of the last century; Maurizio is only eight years old: one night his father comes home with a stereo system that will change his entire life. From that moment, his passion for audio reproduction systems is ignited. At the beginning it is little more than an interest he shares with many of his peers, something that fascinates and intrigues him; but as time goes on, this pull grows and in the Eighties Maurizio, now a young man, starts studying engineering at the university.


1992 is a pivotal year: Maurizio decides to challenge himself and he founds a technical design studio for third parties. Those are the years when he designs a specific tonearm that, up to these days, is still mounted on the Gold Note turntables with very few changes: the B-5, a model with an accurate distribution of the weights along its longitudinal axis, which guarantees a perfectly balanced configuration.


Commission after commission, the company achieves a good reputation among the international community, eventually asserting itself as an important boutique of sound engineering. The industrial model proves to be able to offer to the market creativity, engineering and production startup, thus guaranteeing the utmost flexibility at the service of the companies’ needs. The growth of the working group runs parallel to the company development: in the early 2000s, technicians and designers are joined by other figures, like Elena Basciano, Maurizio’s wife, who joins the company as head of human resources, putting to good use the experience she gained as head of many large international corporations. In 2007 Alessio Oronti becomes an associate and enters the executive ranks of the company.


In the meantime, a new type of interlocutors looms on the horizon: no longer just constructors with very specific catalogue requirements, but also distributors without well-established brands, looking for a new one. It’s at this moment that Maurizio, Elena and Alessio realize that it is time to leave the third-party industry. In 2012 Gold Note is founded. It’s the beginning of a new story: many of those who used to be their clients are now competitors; but the market looks promising: from the very start Family sound and design are recognised as the distinctive traits of the brand. Today, more than ten years after that moment, the company controls all the major markets, and it has a well-established reputation both among the experts and the audio enthusiasts as a guarantee of audio excellence. In such a competitive and crowded space as the world of audiophilia, Gold Note is a synonym of reliability, sonic quality, constant research for innovation and respect for the tradition of the Italian sound.
